Aluminum Foil for Lithium Ion Battery
$0.00
| Materials | Aluminum Foil |
| Stock No: | NCZ-F-0017 |
| Purity: | > 99.99% |
| Thickness | 10 micron-2 mm, customization is available on demand |
| Temper | H18 |
| Application | Lithium-Ion Battery |
| CAS Number | 7429-90-5 |
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities & Customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) are available upon request.
Shipping & Delivery
Related products
Aluminum Nanofoam
 Aluminum Metal Foams
| Product Name | Aluminum Foam |
| Stock No. | NCZFF114 |
| CAS | 7429-90-5 |
| Purity | 99.9% |
| Dimension | 100 mm×100 mm, customization is also possible |
| Thickness | 5 mm, customization is also possible |
| Pore size | 2-11 mm, customization is also possible |
| Molecular Formula | Al |
| Molecular Weight | 26.98 g/mol |
| Density | 0.1~0.35 g/cm³ |
| Porosity | 60-90%, customization is also possible |
| Compressive Strength | 44 Mpa |
| Bending Strength | 27 Mpa |
| Acoustic absorptive | 0.48 |
| Tensile Strength | 1.24 MPa |
| Shear Strength | 1.31 MPa |
| Modulus of Elasticity (Compression) | 103.08 MPa |
| Modulus of Elasticity (Tension) | 101.84 MPa |
| Shear Modulus | 199.95 MPa |
| Vickers Pyramid Number | 35 HV |
| Specific Heat | .895 J/g-C |
| Bulk Thermal Conductivity | 5.8 W/m-C |
| Bulk Resistivity | 2.84 × 10-5 ohm – in |
Aluminium Metal Foam Open Cell or Closed Cell in all size, PPI and thickness, Both are Available on demand (Ask for the customization)
Electrical Conductive Nickel Metal Foam
Nickel Metal Foam
| Product Name | Nickel Metal Foam |
| Stock No | NCZFF104 |
| CAS | 7440-02-0 |
| Purity | > 99.9% |
| PPI | 10-95, customization is available |
| Pore Size | 00.5-0.5 mm, customization is available |
| Length | 500 mm, customization is available |
| Width | 500 mm, customization is available |
| Thickness | 1-20 mm, customization is available |
| Porosity | ≥ 95%, customization is available |
| Molecular Formula | Ni |
| Molecular Weight | 58.71 g/mol |
| Melting Point | 1453 °C |
| Boiling Point | 2730 °C |
| Density | 8.90 g/cm³ |
| Surface Density | 346g/m^2 |
Nickel Foam is available in a closed cell as well as open cell, please ask for customization while ordering.
Hot
Platinum Foil Sheets
Platinum Foil Sheets (Pt foil, thickness 0.1 mm, ≥99.99% trace metals basis)
Product: Platinum Foil Sheets (Pt foil, thickness 0.1 mm, ≥99.99% trace metals basis)
| Molecular Formula | Pt |
| Appearance | Solid Foil |
| CAS No. | 7440-06-4 |
| Stock No. | NCZ-F-0012 |
| Molecular Weight | 195.08 |
| Assay | ≥99.99% trace metals basis |
| Density | 21.45 g/cm3 |
| Melting Point | 1772 °C |
| Boiling Point | 3827  °C |
| Storage & Sensitivity | Ambient temperatures |
| Resistivity | 10.6 μΩ-cm, 20°C |
| Young's Modulus | 168 GPa |
| Size | 25 × 25 mm; 50 × 50 mm, 100 x 100 mm (Customization is available on request) |
| Thickness | 0.025 mm, 0.05 mm, 0.1 mm, 0.25 mm, 0.5 mm, 1 mm etc. (Customization is available on request) |
Please send an email at sales@nanochemazone.com for the Size and Thickness customization.
Pure Gold Metal Sheet/Foil
Gold Foil Sheets (Au foil, thickness 0.025 mm, ≥99.9% trace metals basis)
Gold Foil Sheets
Product: Gold Foil Sheets (Au foil, thickness 0.025 mm, ≥99.9% trace metals basis)Â
| Materials | Gold Foil Sheets |
| Chemical Formula | Au |
| Stock No. | NCZ-F-00118-R1 |
| CAS | 7440-57-5 |
| Purity | ≥99.9% |
| Thickness | 0.025 mm, 0.05 mm, 0.1 mm, 0.25 mm, 0.5 mm, 1 mm etc. (Customization is available on request) |
| Molecular Weight | 196.97 |
| EC Number | 231-165-9 |
| PubChem Substance ID | 24856107 |
| Resistivity | 2.05 μΩ-cm, 0°C |
| Boiling Point | 2808 °C(lit.) |
| Melting Point | 1063 °C(lit.) |
| Polished | Both Side Polished, one side polished, without Polish, etc.
(Customizable) |
| Appearance Quality | Foil/Sheet |
| Size | 25 × 25 mm; 50 × 50 mm, 100 x 100 mm (Customization is available on request) |
Please send an email at sales@nanochemazone.com for the Size and Thickness customization.
Pure Platinum Metal Sheet/Foil
Platinum Foil Sheets (Pt foil, thickness 0.1 mm, ≥99.99% trace metals basis)
Platinum Foil Sheets
Pure Platinum Metal Foil SheetsÂ
| Molecular Formula | Pt |
| Appearance | Solid Foil Sheet |
| CAS No. | 7440-06-4 |
| Stock No. | NCZ-F-00122-R1 |
| Molecular Weight | 195.08 |
| Assay | ≥99.99% trace metals basis |
| Density | 21.45 g/cm3 |
| Melting Point | 1772 °C |
| Boiling Point | 3827  °C |
| Storage & Sensitivity | Ambient temperatures |
| Resistivity | 10.6 μΩ-cm, 20°C |
| Young's Modulus | 168 GPa |
| Size | 25 × 25 mm; 50 × 50 mm, 100 x 100 mm (Customization is available on request) |
| Thickness | 0.025 mm, 0.05 mm, 0.1 mm, 0.25 mm, 0.5 mm, 1 mm etc. (Customization is available on request) |
Please send an email at sales@nanochemazone.com for the Platinum Sheet Size and Thickness customization.
Stainless Steel Foam
Stainless Steel Foam
Product: Stainless Steel Foam – 50PPI/3mm
| Stock No. | NCZFF107 |
| PPI | 10 to 110, customization is available |
| Surface Density | 346g/m^2 |
| Purity | ≥99.9% |
| Porosity | ≥95%, customization is available |
| Length | 300 mm, customization is available |
| Width | 300 mm, customization is available |
| Thickness | 3 mm, customization is available |
Stainless Steel Foam Available in Open Cell as well as Closed Cell
Titanium Metal Foil
| Materials | Titanium Metal Foil |
| Stock No. | NCZ-F-0012 |
| CAS | 7440-32-6 |
| Purity | ≥ 99.9% |
| Thickness | 12 μm, customization is available on demand |
| Width | 30~500 mm, customization is available on demand |
| Surface density | 4.506Â g/cm3 |
| Melting Point | 1668 °C |
| Boiling Point | 3287 °C |
| Joint | 1pcs/roll |
| Polished | One/Both Side Polished |
| Polished | One Side Coarse |
Tungsten Metal Foil
Product: Tungsten Metal Foil (W, Purity: 99.9%, Thickness: 12 µm)
| Materials | Tungsten Metal Foil |
| Stock No. | NCZ-F-0014 |
| CAS | 7440-33-7 |
| Purity | ≥ 99.9% |
| Thickness | 12 μm / Customization is available |
| Width | 30~500 mm |
| Surface density | 19.25Â g/cm3 |
| Melting Point | 3422 °C |
| Boiling Point | 5930 °C |
| Joint | 1pcs/roll |
| Polished | One /Both Side Polished |
| Polished | One Side Coarse |
