Germanium Wafers
$0.00
Germanium Wafer
| Product Name | Germanium Wafer |
| Product Code | NCZ-WM-0018 |
| CAS | 7440-56-4 |
| Diameter | 50.8 mm, also available in 3, 5, 6, 12″ (Customization possible) |
| Type | Un-doped (Customization possible) |
| Orientation | <100>/other orientations are also available |
| Surface | Both/Single Side Polished |
| Wafer Thickness | 500 /- 25 µm (Customization possible) |
| Resistivity | 5-40 Ω-cm (Customization possible) |
Please enquire for other wafers having different thicknesses, Diameter, Length, and sizes, etc.
If the item shown is not exactly what you require please let us know by sending us a message
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities & Customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) are available upon request.
