Product Name: Chromium Carbide Cr3C2 Powder

Chromium Carbide Cr3C2 Powder APPLICATION FIELDS

Chromium Carbide Cr3C2 Powder is a ceramic compound that exists in several different chemical compositions: Cr3C2, Cr7C3, and Cr23C6. At standard conditions, it exists as a gray solid.

It is extremely hard and corrosion-resistant.

It is also a refractory compound, which means that it retains its strength at high temperatures as well.

These properties make use as an additive to metal alloys. When chromium carbide crystals are integrated into the surface of a metal it improves the wear resistance and corrosion resistance of the metal and maintains these properties at elevated temperatures.

Cr3C2 powder is mixed with solid nickel-chromium. This mixture is then heated to very high temperatures and sprayed onto the object being coated where it forms a protective layer. This layer is essentially its own metal matrix composite, consisting of hard ceramic Cr3C2 particles embedded in a nickel-chromium matrix.

Cr3C2 prevents large grains from forming in the composite, which results in a fine-grained structure of superior toughness.

Chromium Carbide Cr3C2 Application:

1. Used as high temperature resistant and wear-resistant surface materials
2. Used for welding and flux-cored wire
3. Chromium carbide is useful in the surface treatment of metal components.
4. Chromium carbide is used to coat the surface of another metal in a technique known as thermal spraying.
5. Chromium carbide is used as an additive in cutting tools in order to improve toughness by preventing the growth of large grains.

Chromium Carbide Cr3C2 Properties:

There are three different crystal structures for chromium carbide corresponding to the three different chemical compositions. Cr₂₃C₆ has a cubic crystal structure and a Vickers hardness of 976 kg/mm². Cr₇C₃ has a hexagonal crystal structure and a microhardness of 1336 kg/mm².

Cr₃C₂ is the most durable of the three compositions and has an orthorhombic crystal structure with a microhardness of 2280 kg/mm². For this reason, Cr₃C₂ is the primary form of chromium carbide used in surface treatment.

Please email us for the customization.

Email: contact@nanochemazone.com

Please contact us for customization and price inquiry

Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.

Product Name: Hafnium Carbide Powder

Brief Description of Hafnium carbide powder HfC:

Hafnium carbide ( HfC) is a chemical compound of hafnium and carbon

With a melting point of about 3900 °C it is one of the most refractory binary compounds known.

However, it has low oxidation resistance, with the oxidation starting at temperatures as low as 430 °C

Hafnium carbide is usually carbon deficient and therefore its composition is often expressed as HfCx (x = 0.5 to 1.0). It has a cubic (rock-salt) crystal structure at any value of x

 Application of Hafnium carbide powder HfC:

1. Used for preparation of ultra-high temperature ceramics
2. The reactant in the synthesis of hafnium-containing organometallic polymers
3. Used as an additive in alloys
4. Used in coatings
5. Widely used in microelectronics, semiconductor, aerospace high-temperature resistant material, coating materials, ceramic materials, ceramic target material, etc.

Hafnium carbide Powder related Information

Please email us for the customization.

Email: contact@nanochemazone.com

Please contact us for customization and price inquiry

Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.

Manganese Nitride Powder

Product Name: Manganese Nitride Powder

Manganese Nitride Powder Description:

Manganese Nitride Powder is generally immediately available in most volumes. High purity, submicron and nanopowder forms may be considered. Our factory produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade

Manganese Nitride in Briquettes, as a kind of Nitrogen and manganese alloy additive, its characteristics are: high content of main elements, low content of harmful impurities, Nitrogen utilization is to be improved after add melt. We adopt the continuous nitride process with unique intellectual property rights in mass production, which has stable quality and uniform nitrogen

Manganese Nitride Powder Application:

1. Used for production of special alloy steel, high strength steel, stainless steel, heat-resistant steel products

2.  Application in the field of high nitrogen steel smelting

3. Used as the steel-making additive and endow many excellent performances to steel grade such as strength, toughness, creep resistance, etc.
4. Specialty demonstrated its good market prospects in large diameter steel pipe of transmitting oil and gas strength steel in shipbuilding and automotive.

Basic information of Manganese Nitride Powder

Manganese (atomic symbol: Mn, atomic number: 25) is a Block D, Group 7, Period 4 element with an atomic weight of 54.938045.

In its elemental form, manganese has a silvery metallic appearance.

It is a paramagnetic metal that oxidizes easily in addition to being very hard and brittle.

Manganese is found as a free element in nature and also in the minerals pyrolusite, braunite, psilomelane, and rhodochrosite.

Nitrogen is a Block P, Group 15, Period 2 element.

Nitrogen is an odorless, tasteless, colorless, and mostly inert gas.

It is the seventh most abundant element in the universe, and it constitutes 78.09% (by volume) of Earth’s atmosphere.

Please email us for the customization.

Email: contact@nanochemazone.com

Please contact us for customization and price inquiry

Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.

Zirconium Carbide Powder

Product Name: Zirconium Carbide Powder

Zirconium Carbide Powder Description:

Like most carbides of refractory metals, zirconium carbide is sub-stoichiometric, i.e., it contains carbon vacancies.

At carbon contents higher than approximately ZrC0.98 the material contains free carbon.

ZrC reacts with water and acids and is pyrophoric.

It becomes readily oxidized in the air when exposed to elevated temperatures.

It shows a high amount of corrosion resistance property and contains carbon vacancies.

It reacts with water as well as acids.

Application:

1.Used as an abrasive, in metal cladding, in cermet, incandescent filaments, and cutting tools.

2. The mixture of zirconium carbide and tantalum carbide is an important cermet material.

3. Hafnium-free zirconium carbide and niobium carbide can be used as refractory coatings in nuclear reactors.

4. Zirconium carbide is used extensively as a coating of uranium dioxide and thorium dioxide particles of nuclear fuel.

5. The coating is usually deposited by thermal chemical vapor deposition in a fluidized bed reactor.

6.  High-temperature wear-resistant surface materials

Please email us for the customization.

Email: contact@nanochemazone.com

Please contact us for customization and price inquiry

Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
