Silicon Germanium Wafers
$0.00
Silicon-Germanium Wafers
| Product Name | Silicon Germanium Wafers |
| Product Code | NCZ-WM-0017 |
| CAS | 7440-56-4 |
| Diameter | 50.8 mm, also available in 3, 5, 6, 12″ (Ask for customization) |
| Type | N-Type also available as P-type and without doping |
| Doping | Antimony/Customization possible |
| Orientation | <100>/other orientations are also available |
| Surface | Both/Single Side Polished |
| Wafer Thickness | 500 /- 25 µm (Ask for customization) |
| Resistivity | 10.5 g/cm³ |
Please enquire for other wafers having different thicknesses, Diameter, Length, and sizes, etc.
If the item shown is not exactly what you require please let us know by sending us a message
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities & Customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) are available upon request.
Shipping & Delivery
