Aluminum Diboride Powder

Aluminum Diboride Powder Description

Aluminum boride Powder is an ionic compound, with a hexagonal crystal structure.  Aluminum boride at an absolute temperature slightly 40K (equivalent to -233 ℃) will be transformed into a superconductor. And its actual operating temperature is 20 ~ 30K. To reach this temperature, we can use liquid neon, liquid hydrogen, or closed-cycle refrigerator to finish cooling. Compared to the current industry using liquid helium to cool the niobium alloy (4K), these methods are simpler and more economical. Once it is doped with carbon or other impurities, magnesium diboride powder in a magnetic field, or there is a current passing, the ability to maintain the superconducting is as much as niobium alloys, or even better.

Aluminum Diboride Powder Related Information

Please email us for the customization.

Email: contact@nanochemazone.com

Please contact us for customization and price inquiry

Note: We supply different size ranges of nano and micron size powder as per the client’s requirements and also accept customization in various parameters.

Product Name: Chromium Carbide Cr3C2 Powder

Chromium Carbide Cr3C2 Powder APPLICATION FIELDS

Chromium Carbide Cr3C2 Powder is a ceramic compound that exists in several different chemical compositions: Cr3C2, Cr7C3, and Cr23C6. At standard conditions, it exists as a gray solid.

It is extremely hard and corrosion-resistant.

It is also a refractory compound, which means that it retains its strength at high temperatures as well.

These properties make use as an additive to metal alloys. When chromium carbide crystals are integrated into the surface of a metal it improves the wear resistance and corrosion resistance of the metal and maintains these properties at elevated temperatures.

Cr3C2 powder is mixed with solid nickel-chromium. This mixture is then heated to very high temperatures and sprayed onto the object being coated where it forms a protective layer. This layer is essentially its own metal matrix composite, consisting of hard ceramic Cr3C2 particles embedded in a nickel-chromium matrix.

Cr3C2 prevents large grains from forming in the composite, which results in a fine-grained structure of superior toughness.

Chromium Carbide Cr3C2 Application:

1. Used as high temperature resistant and wear-resistant surface materials
2. Used for welding and flux-cored wire
3. Chromium carbide is useful in the surface treatment of metal components.
4. Chromium carbide is used to coat the surface of another metal in a technique known as thermal spraying.
5. Chromium carbide is used as an additive in cutting tools in order to improve toughness by preventing the growth of large grains.

Chromium Carbide Cr3C2 Properties:

There are three different crystal structures for chromium carbide corresponding to the three different chemical compositions. Cr₂₃C₆ has a cubic crystal structure and a Vickers hardness of 976 kg/mm². Cr₇C₃ has a hexagonal crystal structure and a microhardness of 1336 kg/mm².

Cr₃C₂ is the most durable of the three compositions and has an orthorhombic crystal structure with a microhardness of 2280 kg/mm². For this reason, Cr₃C₂ is the primary form of chromium carbide used in surface treatment.

Please email us for the customization.

Email: contact@nanochemazone.com

Please contact us for customization and price inquiry

Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.

Product Name: Hafnium Carbide Powder

Brief Description of Hafnium carbide powder HfC:

Hafnium carbide ( HfC) is a chemical compound of hafnium and carbon

With a melting point of about 3900 °C it is one of the most refractory binary compounds known.

However, it has low oxidation resistance, with the oxidation starting at temperatures as low as 430 °C

Hafnium carbide is usually carbon deficient and therefore its composition is often expressed as HfCx (x = 0.5 to 1.0). It has a cubic (rock-salt) crystal structure at any value of x

 Application of Hafnium carbide powder HfC:

1. Used for preparation of ultra-high temperature ceramics
2. The reactant in the synthesis of hafnium-containing organometallic polymers
3. Used as an additive in alloys
4. Used in coatings
5. Widely used in microelectronics, semiconductor, aerospace high-temperature resistant material, coating materials, ceramic materials, ceramic target material, etc.

Hafnium carbide Powder related Information

Please email us for the customization.

Email: contact@nanochemazone.com

Please contact us for customization and price inquiry

Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.

Niobium Boride Powder

Product Name: Niobium Boride Powder

Niobium Boride Powder Related Information

Niobium boride powders having NbB, NbB2 and Nb3B4 phases in various amounts and single phase NbB powders were successfully synthesized by using powder metallurgy methods from related metal oxide raw materials in the presence of a strong reducing agent. Nb2O5, B2O3 and Mg powder blends were milled at room temperature

A high-energy ball mill for different time. Subsequently, an undesired MgO phase was removed from the milled powders by HCl leaching to constitute NbB–NbB2–Nb3B4 as final products, and they were subjected to an annealing process at 1500 °C for 4 h to observe probable boride transformation. Characterization was carried out by XRD, DSC, PSA, SEM/EDX, TEM, and VSM. The effects of milling time (up to 9 h) on the formation, microstructure, and thermal behavior of the final products were investigated.

The reduction reaction took place after milling stoichiometric powder blends for 2 h. Nano-sized NbB–NbB2–Nb3B4 powders in high purity were obtained in the absence of any secondary phase and any impurity via mechanochemistry by milling for 5 h and leaching with 4 mol/L HCl. After annealing, pure and nano-sized NbB–NbB2–Nb3B4 powders transformed into a single NbB phase without leaving behind NbB2 and Nb3B4 phases.

Please email us for the customization.

Email: contact@nanochemazone.com

Please contact us for customization and price inquiry

Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
