CPTi Powder
$0.00
CPTi Powder
| Product | CPTi Powder |
| CAS No. | 7440-32-6 |
| Appearance | Dark Gray With Metallic Luster Powder |
| Purity | ≥99%,  ≥99.9%,  ≥95%(Other purities are also available) |
| APS | 1-5 µM, 10-53 µM  (Can be customized),  Ask for other available size range. |
| Ingredient | Cp-Ti |
| Density | 2.3-3.2g/cm3 |
| Molecular Weight | 315.9g/mol |
| Product Codes | NCZ-DCY-217/25 |
CPTi Description:
CPTi Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing
CPTi Powder Related Information :
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
CPTi Powder
CPTi (chemically pure titanium) powder is a high purity titanium metal powder used in various applications requiring excellent corrosion resistance, high strength, low weight, and biocompatibility. It offers superior properties compared to other titanium grades and alloy powders.
Overview of CPTi Powder
CPTi (chemically pure titanium) powder is a high purity titanium metal powder used in various applications requiring excellent corrosion resistance, high strength, low weight, and biocompatibility. It offers superior properties compared to other titanium grades and alloy powders.
CPTi powder is produced by gas atomization process to achieve spherical powder morphology with minimal contamination. It has a particle size range of 15-150 microns generally. The high purity and cleanliness result in excellent flowability, packing density and sinterability.
Some key properties and advantages of CPTi powder include:
CPTi Powder Properties and Characteristics
| Properties | Details |
| Composition | 99.5% minimum Titanium. Low O, C, N, H, Fe impurities |
| Density | 4.5 g/cc |
| Flowability | Excellent due to spherical morphology |
| Sinterability | Excellent, achieves near full density |
| Particle shape | Predominantly spherical |
| Particle size range | 15-150 microns |
| Apparent density | 2.7-3.2 g/cc |
| Purity | Up to 99.995% Ti content |
| Impurities | Low oxygen, nitrogen, carbon, iron |
| Color | Dark gray with metallic luster |
CPTi Powder Key Advantages
High purity improves performance and biocompatibility
Spherical powder morphology provides good flow and packing
Widely used for additive manufacturing, metal injection molding
Corrosion resistance superior to stainless steel in many environments
High strength-to-weight ratio
Non-toxic and non-allergenic
Can be alloyed to modify properties like strength
Cost-effective compared to wrought titanium
CPTi powder is an excellent choice for parts and products requiring the optimum combination of strength, low weight, corrosion resistance, fatigue resistance, and biocompatibility.
It is used for diverse applications in aerospace, medical, automotive, chemical, and consumer industries.
CPTi Powder Composition and Purity Grades
CPTi powder composition has a minimum of 99.5% titanium content. The impurity levels of oxygen, nitrogen, carbon, hydrogen and iron are carefully controlled. Higher purity grades up to 99.995% Ti are also produced.
CPTi Powder Composition
| Element | Weight % |
| Titanium | 99.5% min |
| Oxygen | 0.08% – 0.40% |
| Carbon | 0.03% – 0.08% |
| Nitrogen | 0.01% – 0.05% |
| Hydrogen | 0.005% – 0.015% |
| Iron | 0.05% – 0.25% |
These impurity levels result in retainment of high strength and corrosion resistance associated with titanium metal. Specific alloying additions can also be made to modify properties like strength.
CPTi powder is available in different purity grades depending on requirements:
CPTi Purity Grades
| Grade | Purity | Particle Size | Applications |
| CPTi Grade 1 | 99.5% min | Medium, large | General use |
| CPTi Grade 2 | 99.9% | Fine, medium | Aerospace, medical |
| CPTi Grade 3 | 99.95% | Fine | Medical, dental |
| CPTi Grade 4 | 99.99% | Ultrafine | Implants, high purity uses |
Higher purity reduces risk of toxicity, improves biocompatibility for medical uses. It also improves performance in high temperature applications.
However, higher purity increases cost. So suitable grade is selected based on balanced trade-off for intended application.
CPTi Powder Physical Properties
Key physical properties of CPTi powder which influence its processing and performance:
CPTi Powder Physical Properties
| Properties | Values |
| Density | 4.5 g/cc |
| Melting point | 1668°C |
| Thermal conductivity | 21.9 W/mK |
| Electrical resistivity | 53.8 ohm-cm |
| Young’s modulus | 107 GPa |
| Poisson’s ratio | 0.33 |
| Mohs hardness | 6 |
| Oxidation resistance | Up to 590°C in air |
Density is quite low compared to other metals providing high strength-to-weight ratio
Melting point is moderately high allowing use for elevated temperature applications
Thermal conductivity is lower than other metals like aluminum or copper
Electrical resistivity is relatively high making it suitable for corrosion resistant fasteners and connectors
Hardness is similar to other titanium alloys but lower than high hardness metals
Oxidation resistance improves with higher purity levels
These properties make CPTi suitable for lightweight structural parts needing high mechanical performance and corrosion resistance.
CPTi Powder Mechanical Properties
Mechanical properties represent the strength, hardness, and workability of the material. Important mechanical properties:
CPTi Powder Mechanical Properties
| Properties | Values |
| Tensile strength | 420 – 550 MPa |
| Yield strength | 380 – 470 MPa |
| Elongation | 15 – 30% |
| Hardness | 200-240 HV |
| Fatigue strength | 200-300 MPa |
Tensile and yield strength are moderately high while elongation is reasonable
Fatigue strength is excellent compared to other competing materials
Hardness is similar or slightly lower than titanium alloys
Properties depend on factors like purity, porosity, processing method
Alloying with elements like Al, V, Mo can significantly increase the strength
The combination of good strength, ductility, fatigue life, and hardness provides balanced mechanical performance.
CPTi matches or exceeds the properties of stainless steels at a lower density. It offers the optimum trade-off between high strength and moderate ductility.
| Industry | Application Examples |
| Aerospace | Engine components, airframe parts, fasteners |
| Medical | Implants, prosthetics, instruments |
| Automotive | Valves, connecting rods, springs |
| Chemical | Pumps, valves, tanks, pipes |
| 3D printing | Aerospace and medical components |
| Metal injection molding | Dental instruments, hardware |
| Investment casting | Turbine blades, golf club heads |
Some specific product applications include:
Orthopedic and dental implants
Surgical instruments and bio-implants
Lightweight automotive engine parts like connecting rods
Aerospace hydraulic tubing and components like bushings
Food/chemical industry valves, pumps, pipes
Watch cases, jewelry
Sporting goods like golf clubs, bicycle frames
Additive manufacturing of aerospace and medical parts
The non-toxic property allows use in products which come in contact with food, pharmaceuticals, and biological fluids.
Overall, CPTi powder provides the best balance of properties for lightweight structural parts across multiple industries.
CPTi Powder Specifications
Industrial specifications and standards are used to evaluate CPTi powder quality and to ensure performance consistency:
CPTi Powder Standards
| Standard | Description |
| ASTM B348 | Standard specification for titanium and titanium alloy powders |
| ASTM F67 | Standard specification for unalloyed titanium bars for surgical implants |
| ISO 5832-2 | Implant grade wrought titanium materials |
These standards specify requirements for:
Chemical composition – percentages of titanium and impurity levels
Physical properties like particle size distribution, flow rate, density
Mechanical properties like tensile and yield strength
Production method like argon gas atomization
Quality assurance through sampling, testing and inspection
Packaging and identification requirement
Reputable CPTi powder manufacturers produce material per ASTM standards and provide certification of compliance for critical applications.
CPTi Powder Particle Sizes
| Particle size | Typical size range | Applications |
| Fine | 1-25 microns | Investment casting, MIM |
| Medium | 25-45 microns | Press and sinter, HIP |
| Coarse | 45-150 microns | Thermal and cold spraying |
Fine powder provides high sintered density and surface finish
Coarse powder has better flowability and is used for thermal spraying
Medium size range offers a balance suitable for press-and-sinter
Size distribution is optimized based on final part properties needed
Spherical morphology is maintained across all size ranges
Controlling particle size distribution and morphology is critical to achieve high powder packing density and sintered part quality.
CPTi Powder Apparent Density
| Apparent Density | Characteristics |
| 2.7 – 3.0 g/cc | Unalloyed CPTi powder |
| 3.0 – 3.2 g/cc | Alloyed CPTi powder |
| Up to 50% of true density | Due to voids between particles |
Higher apparent density improves powder flow and compressibility
Alloying elements like Al, V increase particle density
Values up to 60% are possible with optimized powder
High apparent density reduces press cycle time and improves part quality
Maximizing apparent density allows efficient powder pressing and sintering to full density. It improves manufacturing productivity.
CPTi Powder Production
| Method | Details |
| Gas atomization | High pressure argon gas disintegrates molten Ti stream into fine droplets, which solidify into spherical powder |
| Vacuum arc melting | High purity Ti input stock is refined to reduce gaseous impurities like O, N, H |
| Multiple melting | Ensures chemical homogeneity of raw material |
| Sieving | Classifies powder into different particle size distributions |
| Blending | Powders with different particle sizes are mixed in optimized ratios |
Gas atomization enables large scale production of spherical CPTi powder
Multiple steps produce high purity powder with controlled size and morphology
Argon gas prevents contamination during atomization
Post-processing provides customized powder grades for clients
Highly automated equipment allows efficient CPTi powder production with tight control over all attributes like purity, particle size distribution, morphology, and apparent density.
CPTi Powder Handling
| Recommendation | Reason |
| Avoid inhalation | Due to small particle size |
| Use protective masks | Prevent ingestion through nose/mouth |
| Conduct handling in ventilated areas | Reduce airborne powder circulation |
| Use hazmat suits in large operations | Minimize skin contact |
| Ensure no ignition sources nearby | Powder can combust in oxygen atmosphere |
| Follow anti-static protocols | Prevent accidental fire due to buildup of static charge |
| Use non-sparking tools | Avoids possibility of ignition during handling |
| Store sealed containers in cool, dry area | Prevents moisture pickup and reactivity |
Although CPTi powder is relatively inert compared to reactive metal powders, following precautions is necessary to mitigate safety and fire risks.
CPTi Powder Testing
| Test | Details |
| Chemistry analysis | ICP spectroscopy verifies elemental composition |
| Particle size distribution | Sieve analysis determines size distribution |
| Apparent density | Measured as per ASTM B212 standard |
| Powder morphology | Scanning electron microscopy verifies spherical shape |
| Flow rate | Time taken for fixed powder quantity to flow through defined nozzle |
| Tap density | Density measured after mechanically tapping powder sample |
| Compressibility | Monitoring of powder bed density change during compression |
Rigorous testing protocols ensure reliable and consistent high performance of CPTi powder for critical applications.
CPTi Powder Storage
| Factor | Effect |
| Air, oxygen | Moderate oxidation risk above 500°C |
| Moisture | Low corrosion rate at room temperature |
| Hydrocarbons | Risk of fire if allowed to contaminate powder |
| Acids, bases | Low corrosion rates in neutral solutions |
| Organic solvents | Some absorption and discoloration if immersed |
| Elevated temperatures | Increased reactivity with oxygen and nitrogen |
Recommendations:
Store in sealed inert gas filled containers
Keep below 30°C temperature
Open containers only in dry, controlled environments
Limit contact with oxidizing acids and chlorinated hydrocarbons
With proper precautions during storage and handling, CPTi powder exhibits excellent stability and low reactivity.
Comparison With Ti-6Al-4V Alloy Powder
Ti-6Al-4V is a popular alpha-beta titanium alloy powder. Comparison with CPTi:
CPTi vs Ti-6Al-4V Powder
| Parameter | CPTi Powder | Ti-6Al-4V Powder |
| Density | 4.5 g/cc | 4.42 g/cc |
| Tensile strength | 420 – 550 MPa | 950 – 1050 MPa |
| Ductility | 15 – 30% | 10 – 18% |
| Fatigue strength | 200 – 300 MPa | 500 – 600 MPa |
| Corrosion resistance | Excellent | Moderate |
| Oxidation resistance | Excellent | Good |
| Cost | Low | Moderate |
| Toxicity | None | Low |
| Uses | Low temperature applications, prosthetics | Aerospace components, automotive parts |
CPTi provides better ductility and oxidation resistance
Ti-6Al-4V is stronger with higher fatigue strength
CPTi has better bio-compatibility and corrosion resistance
Ti-6Al-4V provides higher strength-to-weight ratio
CPTi is more cost effective while Ti-6Al-4V offers higher performance
CPTi Powder Pros and Cons
Advantages of CPTi Powder:
Excellent corrosion resistance
High strength-to-weight ratio
Good ductility and fracture toughness
Non-toxic and biocompatible
Non-magnetic and thermally stable
Cost-effective compared to titanium alloys
Can be alloyed to enhance properties
Suitable for diverse applications across industries
Limitations of CPTi Powder:
Relatively expensive compared to iron/steel powders
Lower strength than titanium alloys
Moderate high temperature oxidation resistance
Requires protective atmospheres during processing
Susceptible to galling and seizure in sliding contact
Harder to machine compared to steels and aluminum alloys
CPTi Powder FAQs
Q: What are the main advantages of CPTi powder?
A: The main advantages are high strength, low density, excellent corrosion resistance, biocompatibility, thermal stability and cost-effectiveness.
Q: What are the typical applications of CPTi powder?
A: Major applications are orthopedic implants, dental implants, aerospace components, automotive parts, sporting goods, jewelry, chemical equipment, and medical devices.
Q: What are the differences between various CPTi powder grades?
A: Higher purity powder grades (grade 3 and 4) are used for medical implants and high performance applications. Lower grades provide adequate properties at lower cost for industrial uses.
Description
Note: For pricing & ordering information, please get in touch with us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities and customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) is available upon request.
NOTE:
Images, pictures, colors, particle sizes, purity, packing, descriptions, and specifications for the real and actual goods may differ. These are only used on the website for the purposes of reference, advertising, and portrayal. Please contact us via email at sales@nanochemazone.com or by phone at (+1 780 612 4177) if you have any questions.
Only logged in customers who have purchased this product may leave a review.
Related products
17-4PH Stainless Steel Powder
17-4PH Stainless Steel Powder
| Product | 17-4PH Stainless Steel Powder |
| CAS No. | 12597-68-1 |
| Appearance | Fine Metallic Powder |
| Purity | ≥99%,  ≥99.9%,  ≥95%(Other purities are also available) |
| APS | 1-5 µM, 10-53 µM  (Can be customized),  Ask for other available size range. |
| Ingredient | Fe-Cr-Ni-Cu-Nb |
| Density | 7.75g/cm3 |
| Molecular Weight | N/A |
| Product Codes | NCZ-DCY-167/25 |
17-4PH Stainless Steel Description:
17-4PH Stainless Steel Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing
17-4PH Stainless Powder Related Information :
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
17-4PH Stainless Steel Powder
17-4PH is a precipitation hardening stainless steel powder widely used in additive manufacturing across aerospace, medical, automotive, and general engineering sectors. It offers an excellent combination of high strength, good corrosion resistance, and weldability.
Overview of 17-4PH Stainless Steel Powder
17-4PH is a precipitation hardening stainless steel powder widely used in additive manufacturing across aerospace, medical, automotive, and general engineering sectors. It offers an excellent combination of high strength, good corrosion resistance, and weldability.
This article provides a detailed guide to 17-4PH powder covering composition, properties, AM process parameters, applications, specifications, suppliers, handling, inspection, comparisons, pros and cons, and FAQs. Key information is presented in easy-to-reference tables.
Composition of 17-4PH Stainless Steel Powder
The composition of 17-4PH powder is:
| Element | Weight % | Purpose |
| Iron | Balance | Principal matrix element |
| Chromium | 15 – 17.5 | Oxidation resistance |
| Copper | 3 – 5 | Precipitation hardening |
| Nickel | 3 – 5 | Austenite stabilizer |
| Niobium | 0.15 – 0.45 | Carbide former |
| Manganese | 1 max | Deoxidizer |
| Silicon | 1 max | Deoxidizer |
| Carbon | 0.07 max | Strengthener and carbide former |
Copper enables precipitation hardening while chromium provides corrosion resistance.
Properties of 17-4PH Stainless Steel Powder
| Property | Description |
| High strength | Up to 1310 MPa tensile strength when aged |
| Hardness | Up to 40 HRC in aged condition |
| Corrosion resistance | Comparable to 316L stainless in many environments |
| Toughness | Superior to martensitic stainless steels |
| Wear resistance | Better than 300 series stainless steels |
| High temperature stability | Strength maintained up to 300°C |
The properties make 17-4PH suitable for diverse applications from aerospace components to injection molds.
AM Process Parameters for 17-4PH Powder
Typical parameters for printing 17-4PH powder include:
| Parameter | Typical value | Purpose |
| Layer height | 20-100 μm | Balance speed and resolution |
| Laser power | 150-400 W | Sufficient melting without evaporation |
| Scan speed | 400-1000 mm/s | Density versus production rate |
| Hatch spacing | 100-200 μm | Density and mechanical properties |
| Support structure | Minimal | Easy removal |
| Hot isostatic pressing | 1120°C, 100 MPa, 3 hrs | Eliminate porosity |
Parameters tailored for density, production rate, properties and post-processing needs.
Applications of 3D Printed 17-4PH Parts
Additively manufactured 17-4PH components are used in:
| Industry | Applications | Industry |
| Aerospace | Structural brackets, fixtures, actuators | Aerospace |
| Medical | Dental implants, surgical instruments | Medical |
| Automotive | High strength fasteners, gears | Automotive |
| Consumer products | Watch cases, sporting equipment | Consumer products |
| Industrial | End-use metal tooling, jigs, fixtures | Industrial |
Benefits over machined 17-4PH parts include complex geometries, reduced lead time and machining allowances.
Specifications of 17-4PH Powder for AM
17-4PH powder must meet strict specifications:
| Parameter | Specification |
| Particle size range | 15-45 μm typical |
| Particle shape | Spherical morphology |
| Apparent density | > 4 g/cc |
| Tap density | > 6 g/cc |
| Hall flow rate | > 23 sec for 50 g |
| Purity | >99.9% |
| Oxygen content | <100 ppm |
Custom size distributions and controlled moisture levels available.
Prices range from $50/kg to $120/kg based on purity, size distribution and order volumes.
Handling and Storage of 17-4PH Powder
As a reactive material, careful 17-4PH powder handling is essential:
Store sealed containers away from moisture, acids, ignition sources
Use inert gas padding during transfer and storage
Ground equipment to dissipate static charges
Avoid dust accumulation through extraction and ventilation
Follow applicable safety guidelines
Proper techniques ensure optimal powder condition.
Inspection and Testing of 17-4PH Powder
Quality testing methods include:
| Method | Parameters Tested |
| Sieve analysis | Particle size distribution |
| SEM imaging | Particle morphology |
| EDX | Chemistry and composition |
| XRD | Phases present |
| Pycnometry | Density |
| Hall flow rate | Powder flowability |
Testing per ASTM standards verifies powder quality and batch consistency.
Comparing 17-4PH to Alternative Alloy Powders
17-4PH compares to other alloys as:
Testing per ASTM standards verifies powder quality and batch consistency.
| Alloy | Strength | Corrosion Resistance | Cost | Printability |
| 17-4PH | Excellent | Good | Medium | Good |
| 316L | Medium | Excellent | Medium | Excellent |
| IN718 | Very High | Good | High | Fair |
| CoCrMo | Medium | Fair | Medium | Good |
With its balanced properties, 17-4PH supersedes alternatives for many high-strength AM applications requiring corrosion resistance.
Pros and Cons of 17-4PH Powder for AM
| Pros | Cons |
| High strength-to-weight ratio | Lower oxidation resistance than austenitic stainless steels |
| Good combination of strength and corrosion resistance | Required post-processing like HIP and heat treatment |
| Lower cost than exotic alloys | Controlled atmosphere storage needed |
| Established credentials in AM | Difficult to weld and machine |
| Properties match wrought material | Susceptible to pitting and crevice corrosion |
17-4PH enables high-performance printed parts across applications, though not suited for extreme environments.
Frequently Asked Questions about 17-4PH Powder
Q: What particle size range works best for printing 17-4PH alloy?
A: A typical range is 15-45 microns. It provides optimal powder flowability combined with high resolution and dense parts.
Q: What post-processing methods are used on 17-4PH AM parts?
A: Hot isostatic pressing, solution annealing, aging, and machining are typically used to achieve full densification, relieve stresses, and improve surface finish.
Q: Which metal 3D printing process is ideal for 17-4PH alloy?
A: Selective laser melting (SLM), direct metal laser sintering (DMLS) and electron beam melting (EBM) can all effectively process 17-4PH powder.
Q: What industries use additively manufactured 17-4PH components?
A: Aerospace, medical, automotive, consumer products, industrial tooling, and oil and gas industries benefit from 3D printed 17-4PH parts.
Q: Does 17-4PH require support structures during printing?
A: Yes, minimal supports are needed on overhangs and bridged sections to prevent deformation and allow easy removal after printing.
Q: What defects can occur when printing 17-4PH powder?
A: Potential defects are cracking, porosity, distortion, incomplete fusion, and surface roughness. Most can be prevented with optimized parameters.
Q: What hardness is achievable with 17-4PH AM parts?
A: Solution-annealed 17-4PH has 25-30 HRC hardness while aging increases it to 35-40 HRC for enhanced wear resistance.
Q: What accuracy and surface finish is possible for 17-4PH printed parts?
A: Post-processed 17-4PH parts can achieve dimensional tolerances and surface finish comparable to CNC machined components.
Q: What is the key difference between 17-4 and 17-4PH grades?
A: 17-4PH has tighter chemistry control, lower impurities, and reduced sulfur for better ductility and impact properties compared to basic 17-4 grade.
Q: Is HIP required for all 17-4PH AM application?
A: While recommended, HIP may not be mandatory for non-critical applications. Heat treatment alone may suffice in some cases.
304l Stainless Steel Powder
304l Stainless Steel Powder
| Product | 304l Stainless Steel Powder |
| CAS No. | 11143-21-4 |
| Appearance | Metallic Gray or Silver Powder |
| Purity | ≥99%,  ≥99.9%,  ≥95%(Other purities are also available) |
| APS | 1-5 µM, 10-53 µM  (Can be customized),  Ask for other available size range. |
| Ingredient | Fe-18Cr-8Ni |
| Density | 7.9g/cm3 |
| Molecular Weight | N/A |
| Product Codes | NCZ-DCY-338/25 |
304l Stainless Steel Description:
304l Stainless Steel Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing.
304l Stainless Steel Powder Related Information :
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
304l Stainless Steel Powder
304L stainless steel powder is an austenitic chromium-nickel stainless steel powder with low carbon content. It offers excellent corrosion resistance, good formability and weldability, and widely used for powder metallurgy applications. The ‘L’ denotes lower carbon compared to 304 standard grade. The low carbon minimizes carbide precipitation and maximizes corrosion resistance. Powder metallurgy 304L provides a cost-effective alternative to 316L for non-critical applications not needing molybdenum alloying.
Overview
304L stainless steel powder is an austenitic chromium-nickel stainless steel powder with low carbon content. It offers excellent corrosion resistance, good formability and weldability, and widely used for powder metallurgy applications.
The ‘L’ denotes lower carbon compared to 304 standard grade. The low carbon minimizes carbide precipitation and maximizes corrosion resistance. Powder metallurgy 304L provides a cost-effective alternative to 316L for non-critical applications not needing molybdenum alloying.
This article provides an in-depth look at 304L stainless steel powder covering composition, properties, processing, applications, specifications, suppliers, costs, and other technical details.
Composition
The nominal composition of 304L stainless steel powder is listed below:
Table: Typical composition of 304L stainless steel powder
| Element | Weight % |
| Chromium (Cr) | 18-20 |
| Nickel (Ni) | 8-10.5 |
| Manganese (Mn) | <2 |
| Silicon (Si) | <1 |
| Carbon (C) | <0.03 |
| Sulfur (S) | <0.03 |
| Phosphorus (P) | <0.045 |
| Nitrogen (N) | <0.1 |
| Iron (Fe) | Balance |
Chromium and nickel are the main alloying elements. Chromium provides corrosion and oxidation resistance. Nickel enhances ductility, toughness, and weldability.
Manganese and silicon increase strength. Carbon is kept very low for optimum corrosion resistance. Sulfur, phosphorus, and nitrogen are impurities that are minimized.
Properties
Key properties of 304L stainless steel powder in the annealed condition are provided below:
Table: Properties of 304L stainless steel powder
| Property | Value |
| Density | 7.9-8.1 g/cm3 |
| Ultimate Tensile Strength | 505-620 MPa |
| Yield Strength | 205-275 MPa |
| Elongation | ≥40% |
| Hardness | ≤92 HRB |
| Modulus of Elasticity | 190-210 GPa |
| Melting Point | 1400-1450°C |
| Thermal Conductivity | 16 W/m-K |
| Electrical Resistivity | 0.072 μΩ-cm |
The combination of properties make 304L highly useful for a wide range of applications. The austenitic microstructure provides ductility, toughness, and non-magnetic behavior. 304L has excellent corrosion resistance comparable to 316L stainless steel.
By selecting ultra-low carbon powder, carbide precipitation can be avoided to maximize corrosion resistance in critical applications. Strength and hardness can be increased through cold working.
Typical applications for 304L stainless steel powder include:
Food processing equipment
Pharmaceutical tooling
Chemical plant components
Architectural panels, railings
Medical instruments and implants
Marine hardware, fittings, fasteners
Consumer products, appliances
Powder metallurgy mechanical parts
3D printing powders
304L provides cost-effective corrosion resistance versus 316L when molybdenum alloying is not needed for highly corrosive environments. The excellent polishability and non-magnetic properties also suits 304L for architectural cladding and hardware components.
Powder metallurgy is commonly used to produce small precision parts from 304L at high volumes versus machining. Additive manufacturing utilizes 304L powder for prototypes, tooling, and end-use components across industries.
Powder Manufacturing
304L stainless steel powder is commercially manufactured via gas atomization or water atomization processes.
In gas atomization, a high pressure inert gas stream disintegrates the molten metal into fine droplets, producing spherical powders ideal for additive manufacturing and MIM. Particle size distribution is controlled through process parameters.
Water atomization uses high pressure water jets to break up the metal stream into fine particles. This generates irregular, satellite particle shapes. The powder requires post-treatment for additive manufacturing.
Plasma atomization is sometimes used to produce very spherical, clean powders from a metal plasma stream in a controlled inert atmosphere. This ensures high purity and flowability.
Powder Specifications
304L stainless steel powder is commercially available in various size ranges, morphologies, and quality levels. Some typical powder specifications are below:
Table: 304L stainless steel powder specifications
| Attribute | Details |
| Particles sizes | 15-45 μm, 10-100 μm |
| Morphology | Spherical, irregular |
| Apparent density | 2.5-4.5 g/cm3 |
| Tap density | 4-5 g/cm3 |
| Hall flow rate | <30 s/50g |
| Purity | >99.5% |
| Oxygen content | <2000 ppm |
| Moisture content | <0.2% |
Smaller particle sizes below 45 μm are preferred for capturing fine features in additive manufacturing. Spherical particles provide good flowability. Apparent density correlates with powder packing efficiency.
High purity, low oxygen, and controlled moisture levels ensure quality sintered properties. Gas atomized powder offers the best specifications for critical applications.
Standards and Grades
304L stainless steel powder complies with the following standards:
ASTM A240 – Standard for chromium and chromium-nickel stainless steel plate, sheet, and strip
ASTM A313 – Standard for stainless steel spring wire
ASTM A314 – Standard for stainless steel bent wire
AMS 5501 – Stainless steel bars, wire, forgings, tubing with low carbon
AMS 5647 – Stainless steel powder, atomized, 304L
Equivalent grades include:
UNS S30403
Werkstoff No. 1.4306
SUS 304L
SS2348
Powder Storage and Handling
To prevent contamination and maintain powder properties, 304L stainless steel powder should be stored and handled as follows:
Store in sealed containers in a cool, dry environment
Use inert gas purging or vacuum to prevent moisture pickup
Keep away from sparks, flames, and ignition sources
Ground all powder handling and transfer equipment
Avoid contact with contaminants like oil, grease, paints, etc.
Use PPE – mask, gloves, eye protection when handling powder
Powder spills should be promptly cleaned using non-sparking tools and HEPA vacuuming. Powders are moderately sensitive to moisture and air exposure. Proper storage is key.
Metal Injection Molding
304L is widely used for metal injection molding of small, complex parts leveraging powder metallurgy. Key considerations include:
Feedstock:Â 60-68% powder loading with multi-component binder system
Molding:Â High shot size, fast injection speed, high holding pressure
Debinding:Â Solvent debinding followed by thermal debinding
Sintering: 1350-1400°C in hydrogen or vacuum atmosphere
Secondary Operations:Â Machining, laser marking, passivation, electropolishing
MIM service bureaus have established best practices for high-performance 304L parts with as-sintered properties approaching wrought material.
Design for AM
For additive manufacturing using 304L stainless steel powder, key design guidelines include:
Maintain wall thicknesses above 1 mm
Use self-supporting geometries with angles above 45°
Include drain holes to remove unfused powder
Observe build orientation effects on properties
Account for 20-25% shrinkage when designing mating parts
Include machining allowances of 0.5-1 mm for critical fits
Reduce overhangs, bridges, fine details that require supports
Quality control testing performed on 304L stainless steel powder includes:
Chemical analysis – ICP and OES to verify composition
Particle size analysis – Laser diffraction particle size analyzer
Powder morphology – SEM imaging at high magnifications
Apparent density and tap density – Hall flowmeter method
Powder flow rate – Hall flowmeter funnel method
Loss on ignition – ASTM E sin gravity furnace
Moisture analysis – Karl Fischer titration, LECO analysis
For sintered MIM parts, testing includes:
Dimensional tolerances – CMM inspection
Density – Archimedes method
Microstructure – Optical microscopy, image analysis
Mechanical testing – Hardness, tensile, fatigue, Charpy impact
Like most stainless steel powders and parts, 304L poses little health risk with proper handling:
Wear PPE when handling powder – mask, gloves, goggles
Avoid skin contact to prevent sensitization
Use HEPA-filtered vacuum for clean-up of dust and powder
Avoid breathing any welding or melting fumes
Dispose according to local environmental regulations
Ensure adequate ventilation and respiratory protection if grinding or machining sintered parts
No special disposal precautions are needed for 304L. With sound procedures, it poses minimal hazard for workers and the environment.
FAQ
1.What is the difference between 304 and 304L stainless steel powder?
304L has lower carbon content (<0.03%) than 304 (<0.08%) for better corrosion resistance,especially for welding. 304 is more common.
2.Does 304L powder require a controlled atmosphere?
Not necessarily, but storage in sealed containers with inert gas prevents oxidation and contamination.
3.What particle size is best for AM?
15-45 microns is typical for powder bed fusion AM to provide good flow and high resolution. Larger sizes from 45-100 microns are also used.
4.Is 304L used for metal 3D printing?
Yes, 304L is widely used for powder bed and directed energy deposition 3D printing to make prototypes, tooling, and end-use parts.
5.What causes powder to oxidize and lose reusability?
Exposure to air/moisture causes surface oxidation. Proper sealed storage with desiccant and oxygen absorbers prevents this.
6.Does 304L require solution annealing after laser sintering?
Yes, stress relieving at 1050-1150°C and rapid cooling helps restore ductility and toughness after the rapid solidification.
7.What finish can be expected on as-sintered MIM 304L parts?
Around Ra 3-6 microns initially. Polishing and etching can achieve under 0.5 micron. Plating also gives a smooth finish.
8.What tolerance can be achieved with 304L MIM parts?±0.1-0.3% is typical but tolerances under ±0.1% are possible for high precision components.
9.Why is 304L preferred over 304 stainless steel?
The lower carbon gives 304L better corrosion resistance, especially for weldments, reducing sensitization. It has become the dominant grade.
10.What is the cost premium for 304L vs. 304 powder?
Typically 10-30% higher cost for 304L due to the lower carbon composition. Price also depends on quantities ordered.
316L Stainless Steel Powder
316LÂ Stainless Steel Powder
| Product | 316L Stainless Steel Powder |
| CAS No. | 69403-31-0 |
| Appearance | Silvery Powder |
| Purity | ≥99%,  ≥99.9%,  ≥95%(Other purities are also available) |
| APS | 1-5 µM, 10-53 µM  (Can be customized),  Ask for other available size range. |
| Ingredient | Fe-16-18Cr-10-14Ni-2-3-Mo |
| Density | 7g/.9cm3 |
| Molecular Weight | 150-160 g/mol |
| Product Codes | NCZ-DCY-171/25 |
316L Stainless Steel Description:
310L Stainless Steel Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing
316L Stainless Powder Related Information :
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
​316L Stainless Steel Powder(ss316L) 316L is a stainless steel grade, which is classified according to the metallographic structure and belongs to austenitic stainless steel.
Overview of 316L Stainless Steel Powder
316L is an austenitic stainless steel powder widely used in additive manufacturing to produce corrosion resistant parts with good mechanical properties and weldability. This article provides a detailed guide to 316L powder.
Key aspects covered include composition, properties, AM process parameters, applications, specifications, suppliers, handling, inspection methods, comparisons to alternatives, pros and cons, and FAQs. Tables are used to present information in an easy-to-reference format.
The composition of 316L stainless steel powder is:
| Element | Weight % | Purpose |
| Iron | Balance | Principal matrix element |
| Chromium | 16-18 | Corrosion resistance |
| Nickel | 10-14 | Austenite stabilizer |
| Molybdenum | 2-3 | Corrosion resistance |
| Manganese | <2 | Deoxidizer |
| Silicon | <1 | Deoxidizer |
| Carbon | <0.03 | Avoid carbide precipitation |
The high chromium and nickel content provide corrosion resistance while the low carbon minimizes carbide precipitation.
Properties of 316L Stainless Steel Powder
| Property | Description |
| Corrosion resistance | Excellent resistance to pitting and crevice corrosion |
| Strength | Tensile strength up to 620 MPa |
| Weldability | Readily weldable and less prone to sensitization |
| Fabricability | Easily formed into complex shapes |
| Biocompatibility | Safe for contact with human body |
| Temperature resistance | Resistant up to 900°C in oxidizing environments |
Parameters tailored for density, microstructure, production rate and post-processing needs.
Applications of 3D Printed 316L Parts
AM 316L components are used in:
| Industry | Applications |
| Aerospace | Structural brackets, panels, housings |
| Automotive | Turbine housings, impellers, valves |
| Chemical | Pumps, valves, reaction vessels |
| Oil and gas | Downhole tools, manifolds, flanges |
| Biomedical | Dental, orthopedic implants, surgical tools |
Benefits versus wrought 316L include complex geometries, reduced part count, and accelerated product development.
316L powder must meet strict specifications:
| Parameter | Specification |
| Particle size range | 15-45 μm typical |
| Particle shape | Spherical morphology |
| Apparent density | > 4 g/cc |
| Tap density | > 6 g/cc |
| Hall flow rate | > 23 sec for 50 g |
| Purity | >99.9% |
| Oxygen content | <1000 ppm |
Handling and Storage of 316L Powder
As a reactive material, careful 316L powder handling is essential:
Store sealed containers away from moisture, acids, ignition sources
Use inert gas padding during transportation and storage
Ground equipment to dissipate static charges
Avoid dust accumulation through extraction and ventilation
Follow safety data sheet precautions
Proper techniques ensure optimal powder condition.
Quality testing methods include:
| Method | Parameters Tested |
| Sieve analysis | Particle size distribution |
| SEM imaging | Particle morphology |
| EDX | Chemistry and composition |
| XRD | Phases present |
| Pycnometry | Density |
| Hall flow rate | Powder flowability |
Testing per ASTM standards verifies powder quality and batch consistency.
Comparing 316L to Alternative Alloy Powders
| Alloy | Corrosion Resistance | Strength | Cost | Printability |
| 316L | Excellent | Medium | Medium | Excellent |
| 17-4PH | Good | High | Medium | Good |
| IN718 | Good | Very high | High | Fair |
| CoCr | Fair | Medium | Medium | Good |
With its balanced properties, 316L is very versatile for small to medium sized AM components needing corrosion resistance.
Pros and Cons of 316L Powder for AM
| Pros | Cons |
| Excellent corrosion resistance and biocompatibility | Lower high temperature strength than alloys |
| Readily weldable and machinable | Susceptible to porosity during printing |
| Cost advantage over exotic alloys | Prone to thermal cracking |
| Can match wrought material properties | Required post-processing like HIP |
| Range of suppliers available | Lower hardness than precipitation hardening alloys |
316L provides versatile performance at moderate cost, albeit with controlled processing requirements.
Frequently Asked Questions about 316L Stainless Steel Powder
Q: What particle size range works best for printing 316L alloy?
A: A typical range is 15-45 microns. It provides good powder flowability combined with high resolution and density.
Q: What post-processing methods are used on 316L AM parts?
A: Hot isostatic pressing, heat treatment, surface machining, and electropolishing are common methods for achieving full densification and surface finish.
Q: Which metal 3D printing process is ideal for 316L alloy?
A: All major powder bed fusion processes including selective laser melting (SLM), direct metal laser sintering (DMLS) and electron beam melting (EBM) are regularly used.
Q: What industries use additively manufactured 316L components?
A: Aerospace, automotive, biomedical, marine hardware, chemical processing, and oil and gas industries benefit from 3D printed 316L parts.
Q: Does 316L require support structures during 3D printing?
A: Yes, support structures are essential on overhangs and bridged sections to prevent deformation and allow easy removal after printing.
Q: What defects can occur when printing 316L powder?
A: Potential defects are porosity, cracking, distortion, lack of fusion, and surface roughness. Most can be prevented with optimized parameters.
Q: What is the key difference between 316 and 316L alloys?
A: 316L has lower carbon content (0.03% max) which improves corrosion resistance and eliminates harmful carbide precipitation during welding.
Q: How are the properties of printed 316L compared to wrought alloy?
A: With optimized parameters, AM 316L components can achieve mechanical properties on par or exceeding conventionally processed wrought counterparts.
Q: What density can be expected with 3D printed 316L parts?
A: Density above 99% is achievable for 316L with ideal parameters tailored for the alloy, matching wrought material properties.
Q: What finishing is typically applied to 316L AM parts?
A: Abrasive flow machining, CNC machining, and electropolishing are common finishing processes for removing surface roughness and achieving the required tolerances.
430L Powder
430L Powder
| Product | 430L Â Powder |
| CAS No. | 12597-68-1 |
| Appearance | Silvery or Gray Powder |
| Purity | ≥99%,  ≥99.9%,  ≥95%(Other purities are also available) |
| APS | 1-5 µM, 10-53 µM  (Can be customized),  Ask for other available size range. |
| Ingredient | Fe-16Cr |
| Density | 7.7g/cm3 |
| Molecular Weight | 150-160 g/mol |
| Product Codes | NCZ-DCY-174/25 |
430L Description:
430L Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing
430L Powder Related Information :
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
430L Powder
430L powder is a ferritic stainless steel powder containing 17% chromium with additions of molybdenum and niobium for enhanced corrosion resistance. It provides an optimal balance of corrosion resistance, strength, weldability and cost.
Overview of 430L Powder
430L powder is a ferritic stainless steel powder containing 17% chromium with additions of molybdenum and niobium for enhanced corrosion resistance. It provides an optimal balance of corrosion resistance, strength, weldability and cost.
Key properties and advantages of 430L powder:
430L Powder Properties and Characteristics
| Properties | Details |
| Composition | Fe-17Cr-Nb-Mo alloy |
| Density | 7.7 g/cc |
| Particle shape | Irregular, angular |
| Size range | 10-150 microns |
| Apparent density | Up to 50% of true density |
| Flowability | Moderate |
| Corrosion resistance | Excellent in many environments |
| Strengthening | Solid solution and precipitation strengthening |
430L powder is widely used in chemical processing, marine hardware, automotive exhaust components, industrial valves and flanges, and structural parts needing weathering resistance.
430L Powder Composition
| Element | Weight % |
| Iron (Fe) | Balance |
| Chromium (Cr) | 16-18% |
| Carbon (C) | 0.12% max |
| Silicon (Si) | 1% max |
| Manganese (Mn) | 1% max |
| Molybdenum (Mo) | 0.5% max |
| Niobium (Nb) | 0.3-0.6% |
| Nitrogen (N) | 0.03% max |
| Sulfur (S) | 0.03% max |
Iron provides the base matrix and ductility
Chromium enhances corrosion and oxidation resistance
Niobium and molybdenum provide precipitation strengthening
Carbon, nitrogen and sulfur are controlled as tramp elements
The composition is designed to provide optimum corrosion resistance while retaining suitable ductility, toughness and weldability.
430L Powder Physical Properties
| Property | Values |
| Density | 7.7 g/cc |
| Melting point | 1400-1450°C |
| Electrical resistivity | 0.6-0.7 μΩ-m |
| Thermal conductivity | 26 W/mK |
| Curie temperature | 1440°C |
| Maximum service temperature | 650-750°C |
Density is moderately high for a stainless steel
Provides high temperature strength and corrosion resistance
Resistivity higher than pure iron or low alloy steels
Becomes paramagnetic above Curie point
Can withstand moderately high operating temperatures
The physical properties make 430L suitable for corrosive environments and moderately high temperature applications requiring oxidation resistance.
430L Powder Mechanical Properties
| Property | Values |
| Tensile strength | 450-650 MPa |
| Yield strength | 250-350 MPa |
| Elongation | 35-45% |
| Modulus of elasticity | 190-210 GPa |
| Hardness | 80-90 HRB |
| Impact strength | 50-100 J |
Provides moderately high strength for a stainless steel
Excellent ductility and impact toughness
Strength can be further increased through heat treatment
Hardness is relatively low compared to martensitic grades
The properties provide a good combination of strength, ductility, and toughness required for many corrosive environments and load conditions.
430L Powder Applications
| Industry | Example Uses |
| Chemical | Tanks, valves, pipes, pumps |
| Automotive | Exhaust components, fuel injection parts |
| Construction | Cladding, architectural features |
| Oil and gas | Wellhead equipment, drilling tools |
| Manufacturing | Pressing tooling, molds, dies |
Some specific product uses:
Marine hardware like railings, hinges, fasteners
Automotive exhaust manifolds, mufflers, catalytic converters
Chemical processing equipment like valves and flanges
Oil country tubular goods for downhole environments
Architectural paneling, cladding and decorative features
Its excellent corrosion resistance combined with good manufacturability make 430L widely used across industries needing weathering and oxidation resistance.
| Standard | Description |
| ASTM A743 | Standard for corrosion resistant chromium steel castings |
| ASTM A744 | Standard for corrosion resistant chromium steel sheet and strip |
| AMS 5759 | Annealed corrosion resistant steel bar, wire, forgings |
| SAE J405 | Automotive weathering steel sheet |
| DIN 17440 | Stainless steels for corrosion resistant applications |
These standards define:
Chemical composition limits of 430L alloy
Permissible impurity levels like S, P
Required mechanical properties
Approved production methods
Compliance testing protocols
Proper packaging, labeling and documentation
Meeting certification requirements ensures suitability of the powder for the target applications and markets.
430L Powder Particle Size Distribution
| Particle Size | Characteristics |
| 10-45 microns | Ultrafine grade for high density and surface finish |
| 45-150 microns | Coarse grade provides good flowability |
| 15-150 microns | Standard grade for pressing and sintering |
Finer particles allow greater densification during sintering
Coarser powder flows better and fills die cavities uniformly
Size range is tailored based on final part properties needed
Both gas and water atomized powders are available
Controlling particle size distribution allows optimizing processing behavior and final part performance.
430L Powder Apparent Density
| Apparent Density | Details |
| Up to 50% of true density | For irregular powder morphology |
| 3.5-4.5 g/cc typical | Improves with greater packing density |
Higher apparent density improves powder flow and compressibility
Irregular morphology limits maximum packing density
Values up to 60% are possible with spherical powders
High apparent density improves press filling efficiency
Higher apparent density leads to better manufacturing productivity and part quality.
| Method | Details |
| Gas atomization | High pressure inert gas breaks molten metal stream into fine droplets |
| Water atomization | High pressure water jet breaks metal into fine particles |
| Vacuum induction melting | High purity input materials melted under vacuum |
| Multiple remelting | Improves chemical homogenization |
| Sieving | Classifies powder into different particle size ranges |
Gas atomization provides clean, spherical powder morphology
Water atomization is a lower cost process with irregular particles
Vacuum melting and remelting minimizes gaseous impurities
Post-processing allows customization of particle sizes
Automated production and stringent quality control result in consistent powder suitable for critical applications.
430L Powder Handling and Storage
| Recommendation | Reason |
| Use PPE and ventilation | Avoid exposure to fine metallic particles |
| Ensure proper grounding | Prevent static discharge while handling |
| Avoid ignition sources | Powder can combust in oxygen atmosphere |
| Use non-sparking tools | Prevent possibility of ignition during handling |
| Follow safety protocols | Reduce risk of burns, inhalation, and ingestion |
| Store in stable containers | Prevent contamination or oxidation |
As 430L powder is flammable, ignition and explosion risks should be controlled during handling and storage. Otherwise it is relatively safe with proper precautions.
430L Powder Inspection and Testing
| Test | Details |
| Chemical analysis | ICP and XRF verify composition |
| Particle size distribution | Laser diffraction determines size distribution |
| Apparent density | Hall flowmeter test per ASTM B212 standard |
| Powder morphology | SEM imaging shows particle shape |
| Flow rate analysis | Gravity flow rate through specified nozzle |
| Loss on ignition | Determines residual moisture content |
Stringent testing ensures the powder meets the required chemical purity, particle characteristics, density, morphology, and flowability per applicable specifications.
430L Powder Pros and Cons
Advantages of 430L Powder
Excellent corrosion resistance in many environments
Good ductility, toughness and weldability
Cost-effective compared to austenitic grades
Can be precipitation hardened to increase strength
Good high temperature oxidation resistance
Readily formable using conventional techniques
Disadvantages of 430L Powder
Lower strength than martensitic or ferritic grades
Requires care during welding to avoid sensitization
Susceptible to chloride stress corrosion cracking
Limited high temperature tensile strength
Lower hardness and wear resistance than austenitic grades
Surface discoloration over time in outdoor exposure
Comparison With 304L Powder
430L vs 304L Stainless Steel Powder
| Parameter | 430L | 304L |
| Density | 7.7 g/cc | 8.0 g/cc |
| Strength | 450-650 MPa | 520-620 MPa |
| Corrosion resistance | Excellent | Outstanding |
| Heat resistance | Good | Excellent |
| Weldability | Good | Excellent |
| Cost | Low | High |
| Uses | Automotive, construction | Chemical processing, marine |
430L has slightly lower strength but better cost
304L has superior corrosion and heat resistance
430L has better room temperature toughness
304L is preferred for applications above 500°C
430L suited for outdoor structures and automotive parts
430L Powder FAQs
Q: What are the main applications of 430L stainless steel powder?
A: Main applications include automotive exhaust components, chemical processing equipment, oil and gas tools, architectural paneling and cladding, marine hardware, and manufacturing tooling.
Q: What precautions should be taken when working with 430L powder?
A: Recommended precautions include ventilation, PPE, proper grounding, inert atmosphere, avoiding ignition sources, using non-sparking tools, and safe storage in stable containers.
Q: What is the effect of niobium addition in 430L stainless steel?
A: Niobium provides precipitation strengthening through formation of nitrides and carbides. This strengthens the steel while retaining good corrosion resistance and ductility.
Q: How does 430L differ from 409 and 439 stainless steel grades?
A: 430L has higher corrosion resistance than 409 and higher strength than 439. It provides an optimal combination of corrosion resistance, formability, weldability and cost.
AerMet100 Stainless Steel Powder
AerMet100 Stainless Steel Powder
| Product | AerMet 100 Stainless Steel Powder |
| CAS No. | 12060-00-3 |
| Appearance | Gray or Metallic Powder |
| Purity | ≥99%,  ≥99.9%,  ≥95%(Other purities are also available) |
| APS | 1-5 µM, 10-53 µM  (Can be customized),  Ask for other available size range. |
| Ingredient | Fe-13Cr-3Ni-1Mo-0.25C |
| Density | 8.2g/cm3 |
| Molecular Weight | 155-165 g/mol |
| Product Codes | NCZ-DCY-177/25 |
AerMet100 Stainless Steel Description:
AerMet100 Stainless Steel Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing
AerMet100 Stainless Powder Related Information :
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
AerMet100 Stainless Steel Powder
AerMet100 stainless steel powder is an advanced high strength and corrosion resistant alloy powder designed for additive manufacturing applications. With its unique composition and properties, AerMet100 enables production of high performance parts using 3D printing processes like laser powder bed fusion and binder jetting.
This article provides a comprehensive overview of AerMet100 stainless steel powder covering its composition, properties, applications, specifications, pricing, handling, inspection methods and other technical details.
AerMet100 stainless steel powder is a high-performance alloy powder designed for additive manufacturing applications requiring high strength and fatigue resistance. Some key features of this material include:
High strength and hardness – AerMet100 has excellent strength with tensile strength over 200 ksi and hardness ranging from 30-36 HRC.
Good ductility – Despite the high strength, AerMet100 still retains decent ductility and impact resistance. Elongation values are over 10%.
Excellent fatigue resistance – The fatigue limit of AerMet100 is very high at around 50% of tensile strength. This allows durable components exposed to cyclic stresses.
Resistance to creep – AerMet100 resists deformation under load at high temperatures up to 700°C making it suitable for elevated temperature service.
Corrosion resistance – The stainless steel composition provides corrosion and oxidation resistance for use in harsh environments.
Weldability – The low carbon content allows for good weldability using standard fusion welding methods.
Cost-effectiveness – AerMet100 is more affordable than other exotic alloys with similar properties.
This exceptional balance of properties makes AerMet100 suitable for demanding applications in aerospace, oil & gas, automotive, and industrial sectors. Parts made from AerMet100 powder demonstrate high strength-to-weight ratio, durability, and reliability under operating loads.
AerMet100 Stainless Steel Powder Composition
AerMet100 has a martensitic stainless steel composition with additions of cobalt, nickel, and molybdenum for strength and hardness. The nominal composition is given below:
| Element | Weight % |
| Iron (Fe) | Balance |
| Chromium (Cr) | 15.0 – 17.0 |
| Nickel (Ni) | 7.0 – 10.0 |
| Cobalt (Co) | 8.0 – 10.0 |
| Molybdenum (Mo) | 4.0 – 5.0 |
| Manganese (Mn) | < 1.0 |
| Silicon (Si) | < 1.0 |
| Carbon (C) | < 0.03 |
The key alloying elements and their effects are:
Chromium – Provides corrosion and oxidation resistance
Nickel – Increases toughness and ductility
Cobalt – Solid solution strengthener, increases strength
Molybdenum – Solid solution strengthener, increases strength and creep resistance
Manganese & Silicon – Deoxidizers to improve powder manufacturability
Carbon – Kept low for better weldability
The combination of these elements gives AerMet100 stainless steel its unique set of properties.
AerMet100 Stainless Steel Powder Properties
AerMet100 exhibits the following physical and mechanical properties in as-built AM and heat treated conditions:
| Property | As-Built | Heat Treated |
| Density | 7.9 g/cc | 7.9 g/cc |
| Porosity | < 1% | < 1% |
| Surface Roughness (Ra) | 15-25 μm | 15-25 μm |
| Hardness | 30-35 HRC | 34-38 HRC |
| Tensile Strength | 170-190 ksi | 190-220 ksi |
| Yield Strength (0.2% Offset) | 160-180 ksi | 180-210 ksi |
| Elongation | 8-13% | 10-15% |
| Reduction of Area | 15-25% | 15-25% |
| Modulus of Elasticity | 27-30 Msi | 29-32 Msi |
| CTE (70-400°C) | 11-12 μm/m°C | 11-12 μm/m°C |
| Conductivity | 25-30% IACS | 25-30% IACS |
The properties make AerMet100 suitable for high-strength structural components, aerospace fasteners, downhole tools, valves and pumps, and other critical parts where fatigue resistance is paramount.
AerMet100 Stainless Steel Powder Applications
The unique properties of AerMet100 make it an excellent choice for the following applications:
Aerospace
Structural brackets, braces, fuselage components
Landing gear parts, wing components, empennage
Engine mounts, exhaust components
Turbine blades, impellers, compressor parts
High-strength fasteners, bolts, nuts, rivets
Oil & Gas
Downhole drill tools and components
Wellhead parts, valves, pumps
Pressure vessels, pipe fittings
Subsea/offshore structural parts
Automotive
Power generation components
Drive systems parts like gears, shafts
Structural braces, chassis components
High-performance racing components
Industrial
Robotics parts subject to wear and impact
Dies, molds, tooling
Fluid handling parts like valves and pumps
Other high-cycle loaded components
The excellent fatigue strength of AerMet100 makes it an ideal replacement for components traditionally made from titanium or nickel alloys. The high hardness provides good wear resistance as well.
AerMet100 Stainless Steel Powder Specifications
| Specification | Grade/Alloy |
| AMS 7245 | AerMet100 |
| ASTM F3056 | AlloySpec 23A |
| DIN 17224 | X3NiCoMoAl 15-7-3 |
Typical size distributions for AM processing are:
| Particle Size | Distribution |
| 15-53 μm | 98% |
| <106 μm | 99% |
Chemical composition must conform to the permissible ranges for elements like Cr, Ni, Co, Mo, C, etc. as outlined in AMS 7245 specification for AerMet100 alloy.
Mechanical properties should meet or exceed the minimum values for hardness, tensile strength, yield strength, elongation, and reduction of area stated in AMS 7245.
Non-destructive testing like dye penetrant or magnetic particle inspection should show no critical flaws or defects. Powder should have good flowability and exhibit no clumping.
Storage and Handling
To maintain quality of AerMet100 powder for AM use, the following storage and handling guidelines apply:
Store sealed containers in a cool, dry place away from moisture and sources of contamination
Avoid exposing powder to high humidity (>60% RH) for prolonged time
Allow powder to equilibrate to room temperature prior to unsealing container to prevent condensation
Pour and transfer powder in inert environments with low oxygen content if possible
Use powder handling equipment and accessories made from compatible materials to prevent contamination
Limit reuse of powder to 2-3 cycles maximum to prevent degradation of properties
Conduct testing of used powder to ensure it still meets all specifications for reuse
Proper storage and careful handling is key to preventing powder oxidation, contamination, or changes in flowability.
Safety Information
Wear PPE when handling powder – gloves, respirator mask, goggles
Avoid skin contact to prevent possible allergic reactions
Prevent inhalation of fine powders over long periods
Ensure adequate ventilation and dust collection when processing
Use non-sparking tools to dispense and handle powder
Inert gas blanketing is recommended for powder handling
Follow all applicable safety data sheet (SDS) guidelines
Dispose according to local regulations and ensure containment
AerMet100 alloy powders are generally not hazardous materials but following basic safety practices during storage, handling, and processing is advised.
Inspection and Testing
To ensure AerMet100 powder meets specifications, the following inspection and testing procedures can be used:
| Test Method | Property Validated |
| Visual inspection | Powder flowability, contamination |
| Scanning electron microscopy | Particle size distribution and morphology |
| Energy dispersive X-ray spectroscopy | Alloy chemistry, contamination |
| X-ray diffraction | Phases present, contamination |
| Hall flowmeter | Powder flow rate |
| Apparent density | Powder packing density |
| Tap density test | Powder flowability |
| Sieve analysis | Particle size distribution per ASTM B214 |
| Chemical analysis | Composition per AMS 7245, oxides |
| Density measurement | Powder density vs AMS 7245 |
Mechanical testing of printed specimens per AMS 7245 validates final part properties meet requirements. Testing methods include hardness, tensile, charpy impact, high cycle fatigue, low cycle fatigue, creep rupture, fracture toughness, corrosion, etc.
AerMet100 Stainless Steel Powder Comparison to Similar Materials
| Alloy | Strength | Ductility | Weldability | Cost |
| AerMet100 | Very high | Moderate | Fair | Moderate |
| 17-4PH | High | Low | Poor | Low |
| Custom 465 | Very high | Low | Poor | High |
| 316L | Moderate | High | Excellent | Low |
| Inconel 718 | High | High | Moderate | Very high |
Higher strength than 17-4PH and 316L
Better ductility than Custom 465 for higher impact resistance
More weldable than precipitation hardening alloys
Lower cost than Inconel 718
Limitations of AerMet100:
Lower ductility/fracture toughness than austenitic 316L
Inferior weldability compared to 316L
Higher cost than 17-4PH or 316L
Lower strength than Custom 465 in peak aged condition
Overall, AerMet100 provides an optimal combination of strength, ductility, weldability, and cost for high-performance parts made by AM processes.
FAQ
Q: What are the key benefits of AerMet100 alloy?
A: The main benefits of AerMet100 are its high strength and hardness coupled with good ductility, excellent fatigue resistance, creep resistance, corrosion resistance, and moderate cost. This makes it well suited for critical AM applications.
Q: What heat treatment is used for AerMet100?
A: A typical heat treatment is 1-2 hours solutionizing at 1040-1080°C followed by air or furnace cooling to room temperature, then age hardening at 480°C for 4 hours to achieve optimal strength and hardness.
Q: What welding methods can be used to join AerMet100 parts?
A: Fusion welding methods like GTAW, GMAW, and PAW are recommended for AerMet100 to avoid cracking and minimize distortion. Low heat input and peening of welds is also suggested. Brazing can also produce good joints.
Q: How does AerMet100 compare to maraging steels for AM?
A: AerMet100 has higher ductility but slightly lower strength than maraging steels like 18Ni300 or 18Ni350. Maraging steels have poor weldability. AerMet100 is a good lower-cost alternative to maraging.
Q: Can AerMet100 be machined after AM processing?
A: Yes, AerMet100 can be machined after AM but care must be taken to account for work hardening effects. Low cutting forces, carbide tooling, and adequate coolant is recommended. Annealing may be required after extensive machining.
Q: What particle size range of AerMet100 powder is optimal for AM?
A: The recommended particle size range for AM is 15-45 μm. Finer powders improve resolution but can negatively impact flowability. Coarser powders above 53 μm can cause print defects. The typical sweet spot is 25-35 μm.
Al 3003 Powder
Al 3003 Powder
| Product | Al 3003 Powder |
| CAS No. | 7429-90-5 |
| Appearance | Gray Metallic Powder |
| Purity | ≥99%,  ≥99.9%,  ≥95%(Other purities are also available) |
| APS | 1-5 µM, 10-53 µM  (Can be customized),  Ask for other available size range. |
| Ingredient | Al-1.2Mn-0.12Cu |
| Density | 2.73g/cm3 |
| Molecular Weight | 27g/mol |
| Product Codes | NCZ-DCY-179/25 |
Al 3003 Description:
Al 3003 Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing
Al 3003 Powder Related Information :
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
Al 3003 powder
Al 3003 powder is an aluminum alloy powder composed mainly of aluminum and manganese. It belongs to the 3xxx series of aluminum alloys, which are known for their excellent workability and corrosion resistance. The powder form allows for easy handling and processing, making it suitable for various manufacturing techniques.
Overview of Al 3003 Powder
Al 3003 or 3A21 aluminum is a wrought alloy known for its good cold formability, weldability and corrosion resistance. The manganese additions enhance strength through solid solution strengthening while maintaining workability.
Key characteristics of Al 3003 powder include:
Moderate strength with good ductility
Excellent formability and weldability
Good corrosion resistance
High thermal and electrical conductivity
Low density
Available in a range of powder sizes and shapes
Al 3003 powder is used widely in chemical tanks, pipeline, automotive parts, heat exchangers, utensils, and other applications needing moderate strength, formability and corrosion resistance.
Chemical Composition of Al 3003 Powder
| Element | Weight % |
| Aluminum (Al) | Balance |
| Manganese (Mn) | 1.0-1.5% |
| Iron (Fe) | 0.7% max |
| Silicon (Si) | 0.6% max |
| Copper (Cu) | 0.05-0.20% |
| Zinc (Zn) | 0.10% max |
| Magnesium (Mg) | 0.10% max |
| Chromium (Cr) | 0.10% max |
Properties of Al 3003 Powder
| Property | Value |
| Density | 2.73 g/cm3 |
| Melting Point | 645-650°C |
| Thermal Conductivity | 180 W/mK |
| Electrical Conductivity | 43-44% IACS |
| Young’s Modulus | 68-72 GPa |
| Poisson’s Ratio | 0.33 |
| Tensile Strength | 145-185 MPa |
| Yield Strength | 110-140 MPa |
| Elongation | 12-20% |
| Hardness | 35-55 Brinell |
The alloy offers moderate strength with excellent ductility and formability. It has good resistance to atmospheric corrosion. Thermal and electrical conductivity is high.
Production Method for Al 3003 Powder
Commercial production processes used for Al 3003 powder include:
Gas Atomization – Molten alloy stream disintegrated by high pressure inert gas jets into fine spherical powders.
Water Atomization – High velocity water jet impacts and disintegrates molten metal stream to produce fine powders.
Mechanical Milling – Ball milling of aluminum flakes/powders to achieve finer particle sizes and powder characteristics.
Electrolysis – Aluminum produced through electrolysis process and ground to fine powder. Lower purity.
Gas atomization provides the best control over particle size distribution, morphology and microstructure of the powder.
Applications of Al 3003 Powder
Additive Manufacturing – Selective laser melting, binder jetting and other 3D printing processes to produce complex components.
Powder Metallurgy – Compaction and sintering to create parts with good mechanical properties and machinability.
Metal Injection Molding – To manufacture small intricate components for automotive and electronics industry.
Thermal Spraying – Wire arc spraying to deposit Al 3003 coatings offering moderate wear and corrosion resistance.
Welding Filler – Used as filler wire for arc welding and repair of aluminum components.
Pigments – Used in paints and coatings to provide luster and corrosion protection.
Pyrotechnics – Added to pyrotechnic compositions as fuel due to flammability of aluminum.
Specifications of Al 3003 Powder
Al 3003 powder is available under different size ranges, shapes and purity levels:
Particle Size:Â From 10-150 microns for AM methods, up to 300 microns for thermal spray.
Morphology:Â Spherical, granular, flake and irregular particle shapes. Smooth powder flows better.
Purity:Â From commercial to high purity (99.8%) grades tailored for applications.
Flowability:Â Powder customized for flow rates above 25 s/50 g.
Grades:Â Conforming to ASTM B209, EN 573-3, ISO 209:2007 etc. Custom grades offered.
Storage and Handling of Al 3003 Powder
Al 3003 powder should be properly stored and handled to prevent:
Oxidation and reaction with moisture
Dust explosions from powder ignition
Inhalation of fine powder causing health issues
Safety practices advised by supplier should be followed
Inert gas storage, adequate ventilation, grounding, and PPE is recommended when handling the powder.
Testing and Characterization Methods
Key test methods used for Al 3003 powder include:
Chemical analysis using OES or XRF for composition
Particle size distribution as per ASTM B822 standard
Morphology analysis through SEM imaging
Flow rate measurement using Hall flow funnel
Density determination by helium pycnometry
Impurities testing by ICP-MS
Microstructure examination by X-ray diffraction
These testing methods ensure reliable and consistent quality of the aluminum alloy powder.
Comparison Between Al 3003 and Al 6061 Powders
Al 3003 and Al 6061 are two aluminum alloy powders compared:
| Parameter | Al 3003 | Al 6061 |
| Alloy type | Non-heat treatable | Heat treatable |
| Mn content | 1.0-1.5% | 0.15% max |
| Mg content | 0.1% max | 0.8-1.2% |
| Strength | Moderate | Higher |
| Corrosion resistance | Good | Excellent |
| Weldability | Excellent | Good |
| Cost | Lower | Higher |
| Applications | Chemical tanks, utensils | Aerospace, automotive parts |
Al 6061 offers higher strength while Al 3003 provides better weldability and formability at a lower cost.
Al 3003 Powder FAQs
Q: How is Al 3003 powder produced?
A: Al 3003 powder is commercially produced using gas atomization, water atomization, mechanical milling, and electrolysis processes. Gas atomization offers the best control of particle characteristics.
Q: What are the main applications for Al 3003 powder?
A: Key applications include additive manufacturing, thermal spraying, powder metallurgy, metal injection molding, welding filler, pigments, and pyrotechnic compositions.
Q: What is the typical Al 3003 powder size used for laser sintering?
A: For selective laser sintering process, the common Al 3003 powder size range is 20-53 microns with spherical morphology for optimal powder bed density.
Q: Does Al 3003 powder require any special handling precautions?
A: Yes, aluminum powders can be flammable and pose explosion risks. It is recommended to handle them carefully under inert atmosphere using proper grounding, ventilation and PPE.
Al 3104 Powder
Al 3104 Powder
| Product | Al 3104 Â Powder |
| CAS No. | 7429-90-5 |
| Appearance | Silvery-Gray Metallic Powder |
| Purity | ≥99%,  ≥99.9%,  ≥95%(Other purities are also available) |
| APS | 1-5 µM, 10-53 µM  (Can be customized),  Ask for other available size range. |
| Ingredient | Al-1Mn-1Mg |
| Density | 2.72g/cm3 |
| Molecular Weight | 27g/mol |
| Product Codes | NCZ-DCY-183/25 |
Al 3104 Description:
Al 3104 Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing
Al 3104 Powder Related Information :
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
Al 3104 powder
Al 3104 powder is an aluminum alloy composed primarily of aluminum (Al) with small additions of manganese (Mn) and magnesium (Mg). This powder form of the alloy offers distinct advantages in terms of its processability and versatility. It is commonly used in various industries due to its excellent combination of strength, corrosion resistance, and formability.
Overview of Al 3104 Powder
Al 3104 is a 3000 series wrought aluminum alloy known for its good corrosion resistance, excellent formability and weldability. Manganese additions provide strength through solid solution strengthening while maintaining ductility and toughness.
Key characteristics of Al 3104 powder include:
Moderate strength with excellent ductility
Very good weldability and formability
Excellent corrosion resistance
High thermal and electrical conductivity
Low density
Available in various particle size distributions
Al 3104 powder is suitable for chemical tanks, utensils, heat exchangers and applications needing moderate strength combined with good corrosion resistance.
Chemical Composition of Al 3104 Powder
| Element | Weight % |
| Aluminum (Al) | Balance |
| Manganese (Mn) | 1.0-1.5% |
| Silicon (Si) | 0.3% max |
| Iron (Fe) | 0.7% max |
| Copper (Cu) | 0.25% max |
| Magnesium (Mg) | 0.25% max |
| Zinc (Zn) | 0.20% max |
| Chromium (Cr) | 0.05-0.20% |
Properties of Al 3104 Powder
| Property | Value |
| Density | 2.73 g/cm3 |
| Melting Point | 634-643°C |
| Thermal Conductivity | 134 W/mK |
| Electrical Conductivity | 38-42% IACS |
| Young’s Modulus | 70 GPa |
| Poisson’s Ratio | 0.33 |
| Tensile Strength | 150-195 MPa |
| Yield Strength | 95-120 MPa |
| Elongation | 20-30% |
| Hardness | 45-65 Brinell |
The alloy offers moderate strength with high ductility and excellent formability. It has very good resistance to atmospheric corrosion and marine environments.
Production Method for Al 3104 Powder
Common production methods for Al 3104 powder include:
Gas Atomization – Molten alloy stream disintegrated with high pressure inert gas jets into fine spherical powder. Controlled particle size distribution.
Water Atomization – High velocity water jet used to produce fine irregular Al 3104 particles. More economical but higher oxygen pickup.
Mechanical Alloying – Ball milling of aluminum and manganese powder blends followed by cold compaction and sintering.
Gas atomization provides the best control over powder characteristics like particle size, shape and microstructure.
Applications of Al 3104 Powder
Typical applications of Al 3104 powder include:
Metal Injection Molding – To manufacture small intricate components needing moderate strength and good corrosion resistance.
Additive Manufacturing – Suitable for binder jetting and selective laser melting processes to produce complex aluminum parts.
Powder Metallurgy – Press and sinter process to create parts with good mechanical properties and machinability.
Thermal Spraying – Wire arc spray deposition to produce protective coatings offering moderate wear and corrosion resistance.
Welding Filler – Used as filler wire to provide weld strength similar to base metal.
Pigments – Added to paints and plastics to provide shine and corrosion protection.
Specifications of Al 3104 Powder
Al 3104 powder is available under different size ranges, shapes, purity levels and grades:
Particle Size:Â From 10-150 microns for AM methods, up to 300 microns for thermal spray processes.
Morphology:Â Spherical, granular, dendritic and irregular powder shapes. Smooth powder has better flowability.
Purity:Â From commercial to high purity (99.8%) grades tailored for application.
Grades:Â Conforming to ASTM B209, EN 573, ISO 209 specifications. Custom grades offered.
Flowability:Â Powder can be customized for excellent flow rates above 25 s/50g.
Storage and Handling of Al 3104 Powder
Al 3104 powder should be properly handled and stored to prevent:
Oxidation and reaction with moisture
Dust explosion hazards from fine powder
Inhalation related health problems
Safety practices from supplier SDS should be followed
Inert gas blanketing, proper grounding, ventilation, and PPE is recommended when handling the powder.
Testing and Characterization Methods
Key test methods used for Al 3104 powder include:
Chemical analysis using OES or XRF for composition
Particle size distribution as per ASTM B822 standard
Morphology analysis through SEM
Powder flow rate measured by Hall flow funnel
Density determination by helium pycnometry
Impurity testing by ICP-MS
Microstructure examination by X-ray diffraction
These tests ensure batch consistency and compliance with application requirements.
Comparison Between Al 3104 and Al 3003 Powders
Al 3104 and Al 3003 are two aluminum alloy powders compared:
| Parameter | Al 3104 | Al 3003 |
| Alloy type | Non-heat treatable | Non-heat treatable |
| Mn content | 1.0-1.5% | 1.0-1.5% |
| Strength | Slightly lower | Slightly higher |
| Corrosion resistance | Excellent | Excellent |
| Weldability | Excellent | Excellent |
| Cost | Lower | Higher |
Al 3104 offers slightly better formability whereas Al 3003 provides marginally higher strength. Both offer excellent corrosion resistance.
Al 3104 Powder FAQs
Q: How is Al 3104 powder produced?
A: Al 3104 powder is commercially produced using gas atomization, water atomization, and mechanical alloying followed by sintering. Gas atomization provides the best control of particle characteristics.
Q: What are the main applications of Al 3104 powder?
A: The major applications of Al 3104 powder include metal injection molding, additive manufacturing, thermal spray coatings, powder metallurgy parts, pigments, and welding filler wire.
Q: What is the recommended Al 3104 powder size for binder jet 3D printing?
A: For binder jetting process, the typical Al 3104 powder size range is 20-45 microns with near-spherical morphology to enable good powder bed density.
Q: Does Al 3104 powder require any special handling precautions?
A: Yes, it is recommended to handle aluminum powders carefully in inert atmosphere using proper grounding, ventilation and PPE to prevent fire or explosion hazards.
Q: Where can I purchase Al 3104 powder suitable for marine applications?
A: Al 3104 powder with high corrosion resistance tailored for marine environments can be purchased from leading manufacturer.
AlSi10 Powder
AlSi10 Powder
| Product | AlSi10 Powder |
| CAS No. | N/A |
| Appearance | Gray-Silver  Metallic Powder |
| Purity | ≥99%,  ≥99.9%,  ≥95%(Other purities are also available) |
| APS | 1-5 µM, 10-53 µM  (Can be customized),  Ask for other available size range. |
| Ingredient | Al90Si10 |
| Density | 2.67g/cm3 |
| Molecular Weight | N/A |
| Product Codes | NCZ-DCY-190/25 |
AlSi10 Description:
AlSi10 Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing
ALSi10 Powder Related Information :
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
AlSi10 Powder
AlSi10 is an aluminum alloy powder containing 10% silicon and remainder aluminum. It offers an excellent combination of strength, low density, thermal properties, corrosion resistance and weldability.
AlSi10 Powder Composition
| Element | Composition |
| Aluminum (Al) | Balance |
| Silicon (Si) | 9-11% |
Aluminum forms the matrix providing low density, ductility and corrosion resistance.
Silicon provides solid solution strengthening and improves castability.
Strict control of the aluminum to silicon ratio is critical to achieve optimal strength and physical properties. Other minor alloying elements like magnesium, iron, copper or zinc may also be present in certain grades.
Properties of AlSi10 Powder
AlSi10 powder possesses an excellent combination of properties making it suitable for various demanding applications:
| Property | Value |
| Density | 2.7 g/cm3 |
| Melting Point | ~600°C |
| Thermal Conductivity | 150-180 W/m-K |
| Electrical Conductivity | 35-40% IACS |
| Coefficient of Thermal Expansion | 21-23 x 10<sup>-6</sup> /°C |
| Modulus of Elasticity | 80-85 GPa |
| Tensile Strength | 240-300 MPa |
| Elongation | 1-5% |
| Hardness | 80-90 Brinell |
| Corrosion Resistance | Excellent |
Low density – Up to 65% lighter than copper alloys and steels.
High thermal conductivity – Enables rapid dissipation of heat in electronics.
High strength-to-weight ratio – Strength comparable to titanium alloys with lower density.
Excellent weldability and castability – High fluidity when molten allowing easy casting and welding.
Resistant to corrosion and oxidation – Protective oxide layer prevents corrosion in many environments.
This exceptional property profile makes AlSi10 suitable for lightweight structural applications across aviation, space, automotive and other sectors.
Applications of AlSi10 Powder
Owing to its lightweight, strength and thermal properties, AlSi10 powder is ideal for:
| Applications | Benefits |
| Aerospace components | Low density combined with high strength. |
| Automotive parts | Weight reduction without compromising mechanical performance. |
| Electronic housings | Thermal management for heat dissipation combined with low weight. |
| Medical implants | Biocompatible, non-toxic, corrosion resistant. |
| Thermal management | High thermal conductivity to dissipate heat. |
Used extensively in aircraft and rocket components like engine mounts to reduce weight.
Automotive industry uses AlSi10 for pistons, transmission casings, suspension parts to improve fuel efficiency through lightweighting.
Electronic enclosures and heat sinks leverage high thermal conductivity for efficient cooling.
Rewards excellent strength-to-weight ratio with lower density compared to titanium alloys.
Provides excellent biocompatibility, corrosion resistance for medical implants like orthopedic devices.
AlSi10 delivers maximum performance in demanding applications where low mass and high strength are critical.
AlSi10 Powder Specifications
AlSi10 powder is available in various size fractions, shapes and purity levels:
| Parameter | Options |
| Particle size | 5-150 microns |
| Particle shape | Spherical, irregular |
| Apparent density | Up to 2.7 g/cm3 |
| Flow rate | Up to 25 s/50g |
| Purity | Up to 99.7% |
| Alloy variants | AlSi12, AlSi5 |
Smaller particles promote better sintering while larger sizes provide higher flowability.
Spherical morphology improves flow and packaging density. Irregular particles offer cost benefits.
Higher apparent density increases effective loading in composites manufacturing.
Higher flow rates enhance ease of powder handling and processing.
High purity reduces contamination issues during processing and improves final properties.
Range of silicon levels between 5-12% available to balance fluidity and strength.
Powder attributes are customized based on specific application requirements and processing methods.
Consolidation Methods for AlSi10 Powder
AlSi10 powder can be transformed into full density components using techniques like:
| Method | Benefits |
| Additive manufacturing | Excellent geometric freedom for complex shapes. |
| Metal injection molding | High precision net shape capability. |
| Pressing and sintering | Economical for high volume simpler geometries. |
| Extrusion | Continuous production of rods and tubes. |
| Isostatic pressing | Achieves full density and improves properties. |
Powder bed fusion additive manufacturing methods like selective laser melting are popular for prototypes or low volume production.
Metal injection molding offers closest tolerances and excellent surface finish.
Pressing followed by liquid phase sintering is commonly used but secondary processing like extrusion is needed.
Extrusion leverages excellent castability to produce rods, tubes and profiles.
Cold and hot isostatic pressing reduce porosity and increase density.
The consolidation technique influences the microstructure, final properties, geometrical capabilities and productivity.
Heat Treatment of AlSi10 Parts
Solution heat treatment and artificial aging are used to tailor the strength of AlSi10 components:
| Heat Treatment | Details | Purpose |
| Solutionizing | 530-550°C, quench | Dissolve soluble phases |
| Artificial Aging | 150-180°C, 5-10 hrs | Precipitation hardening |
| Annealing | 350°C, slow cooling | Restores ductility |
Solution heat treatment dissolves alloying elements like silicon in the aluminum matrix followed by rapid cooling or quenching.
Subsequent aging treatment causes fine precipitation resulting in considerable hardening.
Annealing helps recover ductility after extensive prior cold working.
Careful control of time and temperature of solutionizing and aging allows customizing mechanical properties as per specific requirements.
Comparison of AlSi10 Powder with Alternatives
| Alloy | AlSi10 | AlSi12 | Al6061 | Al7075 |
| Strength | High | Highest | Medium | Very High |
| Weldability | Excellent | Poor | Good | Poor |
| Corrosion Resistance | Excellent | Excellent | Excellent | Good |
| Thermal Conductivity | High | Medium | Medium | Low |
| Density | Low | Low | Low | Low |
| Cost | Low | High | Medium | High |
AlSi12 has the highest strength but poorer weldability and thermal conductivity.
6061 is a popular general purpose alloy with medium strength and good corrosion resistance.
7075 excels in very high strength but has poor weldability and only moderate corrosion resistance.
AlSi10 provides the best all-round properties with added cost benefits.
For most applications, AlSi10 offers the optimum balance of performance, weldability and cost.
Health and Safety Considerations for AlSi10 Powder
Like any metal powder, AlSi10 powder requires safe handling:
| Hazard | Precautions | PPE |
| Skin/eye contact | Avoid direct contact. Rinse if exposed. | Gloves, goggles |
| Inhalation | Avoid breathing dust. Ensure ventilation. | Respirator |
| Ingestion | Avoid hand-mouth transfer. Wash hands. | – |
| Fire | Use sand. Do not use water. | Protective gear |
Wear gloves, goggles, mask when handling powder.
Avoid skin contact. Wash after exposure.
Store in cool, dry place away from sparks, flames.
Ensure proper ventilation and dust collection.
Refer SDS and local regulations for complete guidelines.
With proper precautions and PPE, AlSi10 powder can be safely handled during storage, processing and operation.
Inspection and Testing of AlSi10 Powder
To ensure quality requirements are met, AlSi10 powder should be tested for:
| Parameter | Method | Specification |
| Chemical composition | OES, XRF, wet chemistry | Conformance to Al, Si, Mg content |
| Particle size distribution | Laser diffraction, sieving | D10, D50, D90 within range |
| Powder morphology | SEM imaging | Spherical shape and flowability |
| Apparent density | Hall flowmeter test | Minimum specified density |
| Flow rate | Hall flow meter test | Maximum flow seconds |
| Impurity levels | ICP or LECO analysis | Low oxygen, moisture content |
Routine testing as per ASTM standards ensures consistency and high quality powder suitable for critical applications.
FAQs
- What is AlSi10 alloy used for?
- AlSi10 is widely used in aerospace, automotive, and electronics applications where low weight and high strength are critical such as engine mounts, pistons, housings, heat sinks.
- Does AlSi10 require heat treatment?
- Yes, solution heat treatment followed by aging can significantly enhance the tensile strength by precipitating alloying elements like silicon.
- What methods can consolidate AlSi10 powder?
- AlSi10 powder can be consolidated to full density using additive manufacturing, metal injection molding, extrusion, and powder compact forging.
- Is AlSi10 weldable?
- Yes, AlSi10 has excellent weldability owing to the silicon alloying addition which improves fluidity in the molten state. This allows easy fusion welding.
- Is AlSi10 powder safe to handle?
- Like any fine metal powder, standard safety precautions should be taken during storage, handling and processing of AlSi10 powder to minimize health and safety risks.
Reviews
There are no reviews yet.
